SECTION 18.18:
ADJUSTING FOOT
STEM ANGLE
KNEE ANGLE
SECTION 18.19:
ADJUSTING
FOOTREST ANGLE
DORSIFLEXION AND
PLANTARFLEXION
To adjust the foot stem angle, loosen the
bolt
, and rotate the foot stem to the
desired position. Tighten the bolt to secure
in position. For the two-piece footrests the
angle can be adjusted independently. For the
one-piece footrest the bolts need to loosen
simultaneously to allow for adjustment.
To adjust the angle of the footrest to
accommodate dorsiflexion and plantarflexion
on the two-piece footplate, loosen or tighten
the hand knob
, underneath the footplate
to the desired position.
To adjust the angle of the footrest to
accommodate dorsiflexion and plantarflexion
on the one-piece footplate, loosen or
tighten the bolt
, on the top surface of the
footplate to the desired position.
