Leckey BeMe User Manual p121
To adjust the back angle through the backrest
interface at the base of the backrest, locate
the bolt
, within the interface.
Completely remove the bolt from the
assembly, separate the interface extrusion
E
, and end caps
F
, from the vertical tubes
and rotate through 180 degrees. Slot the
vertical tubes back into the interface extrusion
and end caps
, and insert the bolt through
all. Tighten the bolt with the nut to secure in
place.
There are six positions of the backrest recline
mechanism, in 5-degree increments, as
indicated by the graphics
, on the side of
the seat. Also two positions of the backrest
interface, of 5-degree difference, as indicated
by the graphics
, on the side of the
interface end caps. Currently showing +10⁰ to
-15⁰.
F
E
