Squiggles Stander - User Manual p25
11.8 ADJUSTING THE
HEIGHT, DEPTH AND
ANGLE OF THE KNEE
CUPS
Each knee cup can be positioned
independently. To adjust the height,
depth and angle of the knee cups, loosen
knob , select the height, angle and
depth required and retighten the knob
securely.
To adjust the width of the knee cup
loosen knob , set to the desired width
then retighten.
11.10 CONTOURED
AND FLAT HEADREST
ADJUSTMENT
The headrest should only be used when
the child is in supine standing. To adjust
the height, depth and angle of the
contoured headrest, loosen the hand
knobs and when set to the desired
position retighten the knobs.
11.9 KNEE PADS
To adjust, lift the front fabric panel,
set the belt to the desired length and
reposition in place.
Minor adjustments to the knee cups and
hip support may be made during use.
Always use caution to ensure
fingers do not become
trapped when height adjusting
the headrest.
