Squiggles Stander - User Manual p29
SECTION 12:
FREQUENT
ADJUSTMENT FOR
DAILY USE
(THERAPISTS/
CARERS/PARENTS)
Parents and carers should be shown
how to make frequent adjustments and
made aware of the safety checks in
section 7 by a technically and clinically
competent person who has been trained
in the use of the product. Leckey
recommend that a written record is
maintained of all parent and carers
who have been trained in the use of this
product.
12.1 TRANSFERRING
THE USER INTO AND
OUT OF THE STANDER
Before transferring the child into the
stander carry out the daily product
inspection as outlined in section 14 of
this user manual.
Before transferring the child into the
product lock all the castors, ensuring that
they are facing outwards to maximise
product stability. Make sure the straps
on the chest, hip support harnesses and
sandals are released and out of the way
to facilitate transfer.
12.2 CHEST AND HIP
SUPPORT HARNESS
To open the chest or hip support harness
unclip one buckle and move the harness
to one side leaving the other buckle
attached. Reverse the process when
placing the user back in the product.
To facilitate transfer into supine
standing, angle the support frame to
its most horizontal position. This will
enable easier positioning of pads and
straps while the child is lying on their
back.
Always secure the hip and
chest support harnesses first.
