INTRODUCTION TO PARTS
Tesla
J1772
1. Tesla Adapter plug
2. Lectron J1772 plug
1
2
4

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lectron J1772 and is the answer not in the manual?

Lectron J1772 Specifications

General IconGeneral
Connector TypeJ1772
Output Current16A
Input ConnectorNEMA 5-15
MaterialThermoplastic
Operating Temperature-22°F to 122°F (-30°C to 50°C)
CompatibilityJ1772 EVs
Input Voltage100-240V AC
Output ConnectorSAE J1772
Max Current16A
Voltage Rating120V-240V
