Reference Manual for Operation
Rio Rancho, NM – USA
Serial Interface & Control Commands
DM1624 General Commands
actpre Active preset number
baud Serial port baud rate
default Set a memory preset to factory defaults
defpre Location of the memory preset recalled on
powerup
desc Device description string
id Device id string
macro Macro command
macroti Macro title
predesc Preset description
premsk Preset load mask
rank Rank of device in group of connected devices
recall Recall a memory preset
run Run a macro
store Store settings to a memory preset location
serial Device serial number string
version Device firmware version
Serial commands are delivered to the unit via the USB
or RS-232 interfaces to allow remote control of the
device. The command language is extremely simple to
ease the task of programming.
DM1624 Audio Input Commands
inact Audio input activity status
incl Audio input clipping status
indel Audio input delay
ingn Audio input gain
iniv Audio input phase invert status
inlb Audio input channel label
inlv Audio input level (dBu RMS)
inmt Audio input mute status
inmttog Audio input mute toggle
inph Audio input phantom power status
inact (input activity)
This command may be used to determine if an audio
input channel is active, meaning that it has less than 3
dB of attenuation assigned to it by the automixing
algorithm. The input channel is specified by using the
address syntax. Addresses must be in the range 1 to 16.
The data type is integer, either “1” meaning that the
channel is active, or “0” meaning that it is not. If the
channel address is wildcarded, then the data type is an
array of integer of size 16.
Examples:
REQUEST RESPONSE
QUERY inact(15)? OK 0
QUERY inact(*)? OK {0,1,0,...,0,0,0}
incl (input clipping)
This command may be used to determine if an audio
input channel is clipping, meaning that it is being
overdriven by the input signal to the point of saturating
the analog to digital converter. The input channel is
specified by using the address syntax. Addresses must
be in the range 1 to 16. The data type is integer, either
“1” meaning that the channel is in clipping, or “0” mean-
ing that it is not. If the channel address is wildcarded,
then the data type is an array of integer of size 16.
Examples:
REQUEST RESPONSE
QUERY incl(7)? OK 1
QUERY incl(*)? OK {0,0,0...,0,0,0}
indel (input delay)
This command may be used as a query to read the
input delay, or as an update to set the delay. The input
channel is specified by using the address syntax.
Addresses must be in the range 1 to 16. The data type
is integer, in the range 0 to 2000, representing the time
delay in one half millisecond increments. If the channel
