14
SPECIFICATIONS AND FEATURES
Operating frequencies:
U.S.: 537.600 to 588.700 MHz and 614.400 to 793.500 MHz
Europe: 537.600 to 862.000 MHz
Frequency selection: 256 frequencies in 100kHz steps per 26MHz wide block
Channel spacing: 100kHz (25kHz programmable)
RF Power output: 100 mW (nominal)
Frequency stability: +/- 0.001%
Deviation: +/- 20 kHz (max)
Spurious radiation: 90 dB below carrier
Equivalent input noise: –126 dBV
Input level: Nominal 2 mV to 300 mV, before limiting.
Greater than 3V maximum, with limiting.
Input impedance: Taps provided for 200, 1k, 10k Ohm
Input compressor: Soft compressor, >30 dB range
Gain control range: 43 dB; semi-log rotary control
Modulation indicators: Dual LEDs indicate modulation level 20dB below
limiting and at the onset of limiting.
Low frequency roll-off
adjustment: –18 dB/octave; 35Hz to 150Hz
Controls: 2 position “OFF-ON” slide switch for noiseless turn on/turn off operation.
Front panel knob adjusts audio gain. Recessed control on side panel adjusts
low
frequency rolloff. Rotary switches on side panel adjust transmitter frequency.
Audio Input Jack: Switchcraft 5 pin locking (TA5F)
Antenna: Fixed, flexible cable.
Battery: Precision compartment auto-adjusts to accept any known alkaline 9 Volt battery.
(We’ve tried 125 different ones!)
Battery Life: 4.5 hours (alkaline); 14 hours (lithium)
Weight: 6.3 ozs. including battery
Dimensions: 3.1 x 2.4 x .75 inches
Emission Designator: 180KF3E
Specifications subject to change without notice
