LEGRAND 10’’ - Page 6

6/15
CONTENTS
10’’ PDUs
19’’ PDUs
Zero-U PDUs
Data sheet: S000093176EN-04 Updated: 29/03/2018 Created: 25/10/2016
Cat. Nos: 6 468 00/01/05/06/07/09/10/11/12/13/14/15/18/1
9/20/21/22/23/24/30/31/32/33/35/36/40/41/42/43/44/
45/50/51/52/53/54/56/57/59/60/61/65/70/75/90/92/94/
95/97/98/99
19” PDUs (continued)
6 468 44 6 468 45 6 468 99
Number of phases 1 1 1
Input voltage 230 V 230 V 230 V
Input current 16 A 16 A 16 A
Maximum power 3.7kW 3.7kW 3.7kW
Termination method Terminal
block**
Terminal
block**
Cable length
Cable material
Cable cross-section
Plug type
Cable retention method Cable
clamp +
guide
Cable
clamp +
guide
Number and type of outlets* 6 C19 with
locking
6 C13 + 1
C19 with
locking
Outlet colour Black Black
Angle of outlets 90° 90°
Number of circuits per phase 1 1
Additional functions Ammeter Ammeter
Casing 1U
aluminium
1U
aluminium
Zero-U
aluminium
Fixings (included) 19’’ reversible bracket + snap-on fixings
* Outlets are equally distributed on each vertical PDU circuit
** Maximum capacity of terminal block 6 mm²
Zero-U PDUs
646850 646851 646852 646853 646854 646856
Number of phases 1 1 1 1 1 1
Input voltage 230 V 230 V 230 V 230 V 230 V 230 V
Input current 32 A 32 A 32 A 32 A 32 A 32 A
Maximum power 7.4kW 7.4kW 7.4kW 7.4kW 7.4kW 7.4kW
Termination method Terminal block** Cord Terminal block** Cord Terminal block** Terminal block**
Cable length 3 m 3 m
Cable material Rubber HO7RNF Rubber HO7RNF
Cable cross-section 3G 4 3G 4
Plug type IEC 60309 32 A
2P+E
IEC 60309 32 A
2P+E
Cable retention method Cable clamp +
rotatative system
Cable clamp +
rotatative system
Cable clamp +
rotatative system
Cable clamp +
rotatative system
Cable clamp +
rotatative system
Cable clamp +
rotatative system
Number and type of outlets* 24 French/Belgian 24 French/Belgian 24 German 24 German 24 UK 24 C13 with
locking
Outlet colour Black Black Black Black Black Black
Angle of outlets 55° 55° 55° 55° 55° 90°
Number of circuits per phase 2 2 2 2 2 2
Identification of circuits (colour-code) Blue/Red Blue/Red Blue/Red Blue/Red Blue/Red Blue/Red
Additional functions 1P+N MCB C16
10 kA
Cat.No. 4 077 00
1P+N MCB C16
10 kA
Cat.No. 4 077 00
1P+N MCB C16
10 kA
Cat.No. 4 077 00
1P+N MCB C16
10 kA
Cat.No. 4 077 00
1P+N MCB C16
10 kA
Cat.No. 4 077 00
1P+N MCB C16
10 kA
Cat.No. 4 077 00
Casing Zero-U aluminium Zero-U aluminium Zero-U aluminium Zero-U aluminium Zero-U aluminium Zero-U aluminium
Fixings (included) 2 button + 2 standard brackets, 2 Minkels brackets + 2 screws
** Maximum capacity of terminal block 6 mm²
