14/15
CONTENTS
10’’ PDUs
19’’ PDUs
Zero-U PDUs
Data sheet: S000093176EN-04 Updated: 29/03/2018 Created: 25/10/2016
Cat. Nos: 6 468 00/01/05/06/07/09/10/11/12/13/14/15/18/1
9/20/21/22/23/24/30/31/32/33/35/36/40/41/42/43/44/
45/50/51/52/53/54/56/57/59/60/61/65/70/75/90/92/94/
95/97/98/99
PDUs can be supplied with a cable input via cable gland by special request (input on front face or on the end).
5.2 MOUNTING SOLUTIONS
1)10’’ and 19’’
Horizontal mounting with snap-on fixing (for square holes 9.5 x 9.5).
Snap-on fixing system included
Snap-on xing
Vertical mounting possible by turning the fixing brackets round and positioning them on the rear of the unit.
Mounting bracket dimensions
