13/15
CONTENTS
10’’ PDUs
19’’ PDUs
Zero-U PDUs
Data sheet: S000093176EN-04 Updated: 29/03/2018 Created: 25/10/2016
Cat. Nos: 6 468 00/01/05/06/07/09/10/11/12/13/14/15/18/1
9/20/21/22/23/24/30/31/32/33/35/36/40/41/42/43/44/
45/50/51/52/53/54/56/57/59/60/61/65/70/75/90/92/94/
95/97/98/99
3) Connection via fast connector or C20 connector (custom configured version)
Connectors mounted on the front panel of the PDU. The PDU is powered via a separate cable that plugs into these connectors.
C20
Wieland GST18 Wago
C20 Wieland GST18 Wago
Type Male Female Female
Nominal current 16 A 16 A 25 A
Voltage 250 VAC 250 VAC 250 VAC
IP 20 20 20
4) Explanation of 19’’ cable entry, rotative cable input, input with cable gland
The end piece on 19’’ PDUs integrates a cable guide.
Zero-U PDUs integrate a rotative cable input (330°).
330º
