LEGRAND Aidcall Touchsafe Pro - Specification

Doc No. FM5541 issue A Page 10
10. SPECIFICATION
Aidcall Part No.
ZNC663
Approvals
Safety
Compliance to EN 62368-1
EMC
Compliance to EMC 2014/30/EU
Radio
Compliance to RED 2014/53/EU
Materials
Compliance to RoHS 2011/65/EU
Transmission
Radio Frequency
169.48125MHz
Radio Range
80m to 100m Typical (indoor)
Radio ID Range
20000001 to 20999999 (factory programmed)
Infrared Peak Wavelength
940nm
Infrared Range
10m to 15m Typical (line of sight)
Infrared ID Range
1 to 99 (user programmable)
Features
Call Button
Rim Embossed Poly Dome: 280 grams operating force
Visual Indicator
Red LED
Neck Lanyard
900mm long x 15mm wide black Polypropylene with Safety Closure
PCB Jumper LK1
Position A = Program ID ~ Position B = Normal Operation
Mechanical
Keypad
Polyester F200 with antimicrobial top layer
Case Material
Infrared permeable PMMA (Black RAL 9005)
Intermediate Ring Material
TPE (Orange)
Flammability Rating
UL 94 HB
Ingress Protection Rating
IP41
Dimensions
78mm x 48mm x 24mm (HxWxD)
Weight
54 grams (including battery)
Power
Battery Type
3.6V ½ Size AA 1.2Ah Lithium Thionyl Chloride
Battery Manufacturers Part No.
SAFT LS14250
Battery Life
4 Years Typical (based on 5 calls per day)
Environmental
Relative Humidity
Non-condensing
Operating Humidity Range
10% to 90% RH
Operating Temperature Range
5
o
C to 40
o
C (indoor residential)
Storage Temperature Range
-20
o
C to 60
o
C
Compatibility
Touchsafe Pro Panel
Software V4.00a onwards
Touchsafe Pro Call Points
Software V4.00a onwards
