LEGRAND Archimod - Page 19

Archimod®
Operating and maintenance manual
19
3 104 51
3 104 52
3 104 53 3 104 54 3 104 55 3 104 56 3 104 57
Type of batteries 12V 7.2Ah or 12V 9Ah maintenance-free sealed lead batteries
KB Series of N.3 battery drawers (N.7 batteries in each drawer)
3 104 51
3 104 52
3 104 53 3 104 54 3 104 55 3 104 56 3 104 57
EN62040-1 Yes
EN62040-2 Yes
EN62040-3 Yes
3 104 51
3 104 52
3 104 53 3 104 54 3 104 55 3 104 56 3 104 57
Operating temperature 0˚ - 40˚ C
Relative Humidity 20% - 80% non condensing
Noise level at 1 m 50/65 dBA
Thermal dissipation
2730
BTU/h
5460
BTU/h
8190
BTU/h
10920
BTU/h
13650
BTU/h
16380
BTU/h
3 104 51
3 104 52
3 104 53 3 104 54 3 104 55 3 104 56 3 104 57
Weight (Kg) (modules and battery
drawers not included)
140 184,5 204 213 197 216
Dimensions L x W x H (mm) 570 x 912 x 2080 (42U)
Protection degree (IP) IP20
Other notes
Batteries
Standards
Environmental conditions
Construction features
