LEGRAND Archimod - Power Modules

Archimod®
Operating and maintenance manual
59
7.2.3 Power Modules
PM status
PM X Info
Mod Model of power module X
SW Vers. Firmware version inside the power module X
HW Vers. Hardware version of the power module X
S/N Serial number of the power module X
Max VA Maximum apparent power suppliable by the power module X [VA]
Max W Maximum active power suppliable by the power module X [W]
Max Icgh Maximum current suppliable by the battery charger of the power module X [A]
PM
Measure-
ments
Input X
Power Active power absorbed by the mains by the power module X [W]
Appar. Power
Apparent power absorbed by the mains by the power module
X [VA]
Vrms. Effective voltage in input to power module X [V RMS]
Bypass Vrms
Effective voltage in input to the power module X
for the bypass line [V RMS]
Linked Vrms Input line voltage to the power module X [V RMS]
I rms
Effective current absorbed by the power module X by the
mains [A RMS]
Peak I Value
Peak current absorbed by the power module X
by the mains [A]
Frequency
Frequency of the sinusoid voltage in input to the power
module X [Hz] for the bypass line
Crest I Factor Crest factor applied by the power module X to the mains
Power factor Power factor applied by the power module X to the mains
Output X
Power Active power supplied by the power module X [W]
Appar. Power Apparent power supplied in output by the power module X [VA]
V rms Effective voltage supplied in output by the power module X [V RMS]
Linked Vrms Line voltage in output by the power module X [V RMS]
I rms Effective current supplied in output by the power module X [A RMS]
Peak I Value Peak current supplied in output by the power module X [A]
Frequency
Frequency of the sinusoid voltage in output from the power
module X [Hz]
Crest Factor Crest factor of the current in output from the power module X
Power factor Power factor in output from the power module X
Max W Maximum active power suppliable by the power module X [W]
Power
Active power supplied by the power module X,
expressed as a percentage in relation to the maximum active
power the power module X can supply [%]
Max VA
Maximum apparent power suppliable
by the power module X [W]
App. Power
Apparent power supplied by the power module X,
expressed as a percentage in relation to the maximum
apparent power the power module X can supply [%]
(continue)
