ATTENTION
the type and cross section of the connecting cables must be chosen according to their operating current and laying
must be as established by existing laws; this is the responsibility of the installer. The UPS input current and output
power are given in paragraph 2.4 and the battery current in Table 7.
WARNING
The following tables give only an indication of the cable cross sections to use as far as concerns using unipolar
cables, with single insulation, in PVC and laid in a pipe above ground.
TABLE 1
Minimal Recommended Cable Sections for UPS Archimod®
TABLE 2
UPS Archimod® Recommended battery fuse ratings
11. Tables
POWER INPUT PHASES OUTPUT PHASES INPUT CABLE OUTPUT CABLE INPUT Imax
20 kVA
3 3 5 x (10 mm
2
) 5 x (10 mm
2
) 37 A
1 1 3 x (25 mm
2
) 3 x (25 mm
2
) 111 A
1 3 3 x (25 mm
2
) 5 x (10 mm
2
) 111 A
3 1 5 x (25 mm
2
) 3 x (25 mm
2
) 111 A
40 kVA
3 3 5 x (25 mm
2
) 5 x (25 mm
2
) 74 A
1 1 3 x (95 mm
2
) 3 x (95 mm
2
) 222 A
1 3 3 x (95 mm
2
) 5 x (25 mm
2
) 222 A
3 1 5 x (95 mm
2
) 3 x (95 mm
2
) 222 A
60 kVA 3 3 5 x (35 mm
2
) 5 x (35 mm
2
) 111 A
80 kVA 3 3 5 x (50 mm
2
) 5 x (50 mm
2
) 148 A
100 kVA 3 3 5 x (70 mm
2
) 5 x (70 mm
2
) 185 A
120 kVA 3 3 5 x (95 mm
2
) 5 x (95 mm
2
) 222 A
POWER BATTERY FUSE
UPS Archimod®
FB+ FB-
20 kVA 1 x 100A 500V gG (22 x 58) 1 x 100A 500V gG (22 x 58)
40 kVA 2 x 100A 500V gG (22 x 58) 2 x 100A 500V gG (22 x 58)
60 kVA 3 x 100A 500V gG (22 x 58) 3 x 100A 500V gG (22 x 58)
