7. Control panel
Note: press “ENTER” to change the X value and consequently vary the phase of which you are reading the data.
UPS Info
Archimod® Model Equipment model
Synchr. address Synchronisation address for this command
CM number Number of commands recognised
Max VA Maximum suppliable apparent power [kVA]
Max W Maximum suppliable active power [kW]
Max Icgh Maximum current that can be supplied for charging the batteries [A]
SW vers. Firmware version of the control
PM SW vers. Firmware version of the power modules
Boot Ver. Bootloader version in the command
S/N UPS serial number
Measurements Output X
Power Active power supplied in output by the UPS on phase X [W]
App.Pow. Apparent power supplied in output from the UPS on phase X [VA]
V rms Effective voltage supplied in output from the UPS on phase X [V RMS]
Line Vrms
Effective line voltage between the phases in output
from the UPS V RMS]
I rms Effective current supplied in output from the UPS on phase X [A RMS]
Peak I Val. Peak current supplied in output from the UPS on phase X [A]
Frequency Frequency of the sinusoid voltage in output from phase X [Hz]
Crest I Factor Crest factor on phase X
Power Factor Power factor of the load connected to the UPS on phase X
Max W Maximum active power suppliable by the UPS on phase X [W]
Power
Active power supplied by the UPS on the X phase,
expressed as a percentage in relation to the maximum
active power the UPS can supply on the X phase [%]
Max VA Maximum apparent power suppliable by the UPS on phase X [W]
Appar. Power
Apparent power supplied by the UPS on the X phase, expressed as
a percentage in relation to the maximum apparent power the UPS
can supply on the X phase [%]
UPS config.
OUT Single-phase/Three-phase 120°/3 indep. phases
IN Single-phase/Three-phase/inverse three-phase/Undefined
PM X/Y - X/Y - X/Y
X Power modules divided by phase controlled by this command
Y Power modules divided by phase controlled by the UPS
BCM number Number of battery charger modules recognised
KBs installed Number of KBs installed (1 KB = 3 battery boxes)
Batt. Cap. Capacity of the batteries installed in Ah
No. Batt. per KB Number of batteries in series in one KB
7.2.1 UPS Status
