36
®
Archimod® Three-phase/Three-phase UPS (without separate bypass line)
6. Installation
Nin Nout
L1in
brown
black
grey
blue blue
blue blue
brown
black
grey
blue
L2in
L3in
L1out
L2out
L3out
brown
black
grey
blue
Nin Nout
L1in
L2in
L3in
L1out
L2out
L3out
L1byp
L2byp
L3byp
Nbyp
Archimod® Three-phase/Three-phase UPS with separate bypass line
