Archimod®
Operating and maintenance manual
39
Archimod® 20kVA-40kVA Three-phase/Single-phase UPS (with separate bypass line)
Nin
Nout
L1in
L2in
L3in
L1out
L1byp
Nin
Nout
L1in
L2in
L3in
L1outNbyp
brown
brown
black
grey
blue
brown
black
grey
blue
blue blue
blue blue
Archimod® UPS back panel - Plugging in the EC15 connector
