LEGRAND Archimod - Differential Breaker - Differential Current; Battery current (100% load at the end of discharge) and minimal recommended cable sections

80
®
11. Tables
TABLE 6
Differential Breaker - Differential Current
TABLE 7
Battery current (100% load at the end of discharge) and minimal recommended cable sections
POWER DIFFERENTIAL BREAKER  DIFFERENTIAL CURRENT
20 kVA >= 300 mA
40 kVA >= 300 mA
60 kVA >= 300 mA
80 kVA >= 300 mA
100 kVA >= 300 mA
120 kVA >= 300 mA
POWER BATTERY CURRENT MINIMUM WIRES SECTION
20 kVA 88 A 1 x 25 mm
2
per pole
40 kVA 176 A 1 x 70 mm
2
per pole
60 kVA 264 A 2 x 50 mm
2
per pole
80 kVA 352 A 2 x 70 mm
2
per pole
100 kVA 440 A 2 x 95 mm
2
per pole
120 kVA 528 A 3 x 70 mm
2
per pole
