64
Connect in series the two new blocks to the ones already in the drawer using the cable provided and respecting the po-
larity (connect a positive terminal to a negative terminal).
Connect the free terminals of the two batteries located close to the handle of the drawer to the cables that go to the back
of the drawer. Check the correct polarity of the whole cabling.
Insert the remaining terminal covers on the batteries.
4. Installation
