3
All loads in the room turn OFF immediately after entering PnL, then one load will turn ON. This is Load #1, which is bound to switch
button #1 and occupancy sensors as part of the Plug n’ Go factory default setting. All switch buttons and sensors that are bound to
this load have their blue LED solid ON.
Step 2 Load selection.
Press and release the Config button to step through the loads connected to the DLM local network. As each load turns ON note the
devices (switch buttons and sensors) that are showing a bright solid blue LED. These devices are currently bound to the load that is ON.
The blue LED on the room controller or plug load controller connected to the load is also lit.
• To unbind a switch button from a load, press the switch button while its blue LED is ON bright. The blue LED goes dim to indicate
the button no longer controls the load that is currently ON.
• To unbind an occupancy sensor, press the up () or down () adjustment button while its blue LED is ON. The blue LED turns
OFF to indicate the sensor no longer controls the load that is currently ON.
• Pressing the switch or up () or down () button again while the load is ON rebinds the load to the button or sensor and the blue
LED illuminates brightly.
Step 3 Exit Push n’ Learn.
Press and hold the Config button until the red LED turns OFF, approximately 3 seconds.
TROUBLESHOOTING
Loads do not operate as expected.
LEDs on a switch or sensor
don’t light.
1. Check to see that the the device is connected to the DLM local network.
2. Check for 24VDC input to the device: Plug in a different DLM device at the device location.
If the device does not power up, 24VDC is not present:
• Check the high voltage connections to the plug load controller.
• If high voltage connections are good and high voltage is present, recheck DLM local network
connections between the device and the plug load controller.
The wrong lights and plug
loads are controlled.
1. Configure the switch buttons and sensors to control the desired loads using the Push n’ Learn
adjustment procedure.
LEDs turn ON and OFF, but
load doesn’t switch.
1. Make sure device is not in PnL.
2. Check load connections to room controllers and/or plug load controllers.
