Technical specifications
Linear
Input impedance 47 kOhm
Maximum gain setting +0 dB, +10 dB, +18 dB, +20 dB
switchable on bottom side
Analogue frequency
response
10 Hz (-0,3 dB) to 35 kHz (-1 dB)
Analogue S/N ratio > 95 dB at +0 dB gain
Analogue THD < 0,001 % at 6 mW/300 Ohm
Channel separation > 70 dB/10 kHz
Power output
≠
300 Ohm/200 mW
≠
60 Ohm/400 mW
Output impedance
≠
Line out 60 Ohm
≠
Phones out 5 Ohm
Audio Connections
≠
Neutrik headphone sockets with gold-plated contacts
≠
1 x switching line out, 1 x non-switching line out
≠
gold-plated RCA sockets with teflon insulation
≠
stereo mini jack socket (loop out/line in) 3.5 mm
Mains connections 230 V AC
Fuse 250 mA, Slo-Blo
Power consumption in
operation
ca. 10 W through internal, regulated power supply
Enclosure dimensions
W x D x H
280 mm x 110 mm x 44 mm
Weight 1,5 kg net
USB converter (Linear USB)
Digital sampling rate up to 48 kHz
Word length 16 Bit
Maximum level USB-DAC 1 V eff.
Frequency response USB 10 Hz to 20 kHz (-1,5 dB)
USB standard fully compatible with USB 1.0
Accessories
Mounting kit
A mounting kit developed by Lehmannaudio is available at specialist retailers.
With this accessory the Linear can be mounted horizontally or vertically under
a table or on the wall. A suitable drilling template is included in the mounting
kit. This must only be used with the original mounting frames. The C-frames
should be screwed to the unit only with the countersunk bolts supplied with the
mounting kit.
