Settings:
Gain:
MM/MC Lo/Hi Gain
Down Down 37dB
Down Up 47dB
Up Down 56dB
Up Up 66dB
Termination:
1 2 3 Capacitance
Off Off Off 47pF
Off Off On 147pF
Off On Off 267pF
Off On On 367pF
On Off Off 1047pF
On Off On 1147pF
On On Off 1267pF
On On On 1367pF
4 5 6 Impedance
Off Off Off 47 kOhms
Off On Off 1000 Ohms
On Off Off 100 Ohms
On On Off 91 Ohms
Off Off On Custom Impedance
Please have a look at the manual of your cartridge to get to know the recommended impedance .
Again: You can adjust the settings for gain and termination separately. So you can easily realize MC at
66dB gain and 47 kOhms termination.
Problems with radio frequency interference with an MC cartridge can normally be solved by using the cap
switches. If the maximum capacitance is not enough, additional capacitors can be added by using the
custom impedance slot. The maximum recommended capacitance can be up to 5 nF. This is highly
dependant on the output impedance of the cartridge itself.
