Group 7 Data/Programming Page 151
Release R2.0 LEIBINGER JET3
The dialog box allows carrying out a temporary test of the inputs and outputs of the
LEIBINGER JET3 during the troubleshooting without any additional tools.
If signals are fed to the inputs the signal status are displayed in the dialog box. The
functions which are assigned to the inputs are not carried out for feeding the signals!
Active in-/outputs are displayed by a green status display.
For leaving the dialog box all carried out settings will be rejected, that means if
outputs have been defined just for testing (activated) they will be deactivated again.
7.4.2 Hydraulic-/Printhead – and special functions
SERVICE WORK AND SPECIAL FUNCTIONS
This work must only be carried out by trained personnel or by Leibinger
service technicians!
By pressing the direct button [icon] <Service> (1) or with the options <Printhead>
(3) or <Hydraulic> (4) you can open the dialog box „Hydraulic/Printhead Test“ (5).
This dialog box provides the verification of hydraulic components, activation or
deactivation and setting of print head functions as well as the processing of special
functions. All changes have only a temporary effect, that means as long as the dialog
box is open.
The selection of a tab happens by clicking on the accordant tab (8).
Note: The proceeding corresponds to the Windows™-standard procedure.
By pressing the button <Emergency off> (6) the JET3 is turned off immediately,
without carrying out further actions (e.g. closing the nozzle).
The button <Close> (5) closes the dialog box.
By closing the dialog box all changes are reset to the normal/fully
automatic operating condition!
If the dialog box closes an accordant message (9) is faded in which can
confirm or cancel the quitting.
