Group 8 Job editor Page 233
Release R2.0 LEIBINGER JET3
8.4.5 ICG-value (Inter Character Gap)
The setting determines the distance between the several characters. As larger the
character distance has been selected, as more „Blank strokes“ are inserted between
the single characters. The value can be set between 0 – 7.
Example
0 = no distance between the characters
1 = 1 blank stroke is generated between the characters
…..
7 = 7 blank strokes are generated between the characters
The set value is shown on the accordant display field.
Explanation:
A stroke is a complete dot line in
vertical direction (dot height).
Figure 125
Object settings (ICG)
8.4.6 Orientation
With the drop-down list <Orientation> (1) you can rotate the printing object by
90°/180° or 270° .
Figure 126
Object settings (Orientation)
1 – Drop-down list <Orientation>
1
Display:
normal 90° 180° 270°
Display: ICG=0 ICG=1 ICG=7
ICG
ICG
Example:
