Group 8 Job editor Page 249
Release R2.0 LEIBINGER JET3
To control the print-out of the JET3, a so called Print-Go signal is required. It can be
generated internally, depending on the set printing parameters, as well as externally
by a sensor (e.g. light barrier, product sensor etc.).
This sensor is called as Print-Go source.
Extern: If this function is activated an external sensor has to be connected to the
interface X5 of the LEIBINGER JET3.
Pos. edge:
Neg. edge:
Note: The product sensor 24V can be NPN- or PNP-connected.
Internal: If this function is activated a print is generated depending on the set
printing parameters.
Note: A connected sensor is not inquired.
PrintGo-source/Print start control
