8.5.1.7 PrintGo-Gate
(Print start control)
This function offers an additional option to control the print start. With this function
enabled the print out starts only as long as the monitored sensor is active during the
PrintGo signal.
The inputs for the sensor signals are located on the connector of interface X5 of the
LEIBINGER JET3.
Figure 136
PrintGo-Gate /Print start control
Activating options:
 High-Level active:
 Low-Level active:
PG signals
Gate
PG signals
Gate
Signals are
disabled and not
carried out!
!
