Open the dialog box for the interface settings from the main window of the printer:
<Extra> - <Interface setting> (1).
The dialog box (2) for the interface settings offers several options. First you can
choose the <Connection type> (3). The displayed options depend on the selected
type of connection. E.g. the serial interface for extern text offers input fields for the
baud rate (4) and the parity settings (5).
Extern Text for serial interface
After the connection type <Extern Text for serial interface> (6) is selected you can
choose the baud rate (10) and the kind of parity (7) from a drop-down lists. With the
<OK> button all settings are saved and the dialog box is closed (8). With the
<Cancel> button (9) all changes are discarded and the dialog box is closed without
saving.
Extern Text for Ethernet interface
After the connection type <Extern Text Ethernet> (11) is selected you can set the
<Port> number (16) for the connection. Clicking in the display field (12) will open
a numeric keypad (13) for inputs. Alternatively you can use the arrow keys of the
display field (14). You can save all settings and close the dialog box with the <OK>
button (15). The <Cancel> button (16) will discard all changes and close the dialog
box without saving. If you use the Ethernet interface you will have to make sure that
the IP-address settings of the printer are correct. For this you will have to open the
respective dialog box from the main window of the printer:
<Settings>-<Basic Settings>-<IP-Address> (18, 19)
The tab shows the current settings (20). You will have to make sure that the IP
addresses of the printer and of the device used for the connection (e.g. Notebook)
are within the same logical address space respective within the same network.
