Proceeding
(Example: Filling of solvent)
WARNING
Risk of fire and injury! Absolutely observe!
 Before filling the device with the consumables, measures for the
electrostatic discharge have to be made!
 Highly flammable! Burning gases and liquids may cause severe
burns. Keep sources of ignition away from the printer!
 Always statically discharge the printer and yourself before filling the
reservoirs! Simply touch the housing of the printer to discharge the
equipment and stand on a grounded surface wearing ESD shoes
during filling!
 Protective equipment is necessary! Read the safety data sheets and
the personal protective equipment rules and regulations!
ATTENTION
The sealing of the refill bottle must not be opened!
 Open the lid (2) of the reservoir tank unit(1).
 Open the screw cap of the solvent tank (4) and of the refill bottle (5).
 Put the refill bottle on the solvent tank. The seal of the bottle will be breached and
the closing valve of the tank will open automatically and the reservoir tank is filled
up.
 Wait until the refill bottle is completely empty.
 Take out the empty refill bottle. The closing valve of the reservoir tank will be
closed automatically.
 Finally close the reservoir tank and empty refill bottle carefully with the srew caps.
ATTENTION
The reservoir tanks as well as the empty refill bottles have to be closed
carefully after filling.
