How to fix a Leica Geosystems Receiver RX1200 that does not turn on?
If your Leica Geosystems Receiver RX1200 doesn't turn on, ensure that the battery is fully charged. Check the clip-on connection to GPS1200 and the cable connection to the GPS1200 RX1200 port. Verify the connection to a fully charged battery.
What to do if my Leica Geosystems Receiver RX1250 does not connect to PC?
If your Leica Geosystems Receiver RX1250 doesn't connect to a PC: * Try another USB port. * Verify the device is detected and the driver is loaded. * Check the Bluetooth device settings in Device Management. * Review Bluetooth device settings, including Options and COM ports. * Confirm ActiveSync is running and the correct COM port is defined in Connection Settings. * Reboot the PC and/or RX1250.
Why my Leica Geosystems Receiver RX1200 does not connect to TPS1200?
If your Leica Geosystems Receiver RX1200 doesn't connect to TPS1200, ensure the TPS1200 is set to work in RCS mode. Verify that the base radio is connected to the instrument and a fully charged external battery. Make sure the RX1220 and the base radio are within radio range. Check that the radio settings in RX1220 and the base radio are correct. Synchronize radio settings to Leica default values.
How to improve radio range on a Leica Geosystems RX1200 Receiver?
If the radio range of your Leica Geosystems Receiver is not optimal: * Ensure the TCPS27B is mounted onto the tripod using the adapter. * Change the link number to reduce interference from other 2.4 GHz radios. * Make sure the RX1220 faces the instrument without obstructions between the antennas.
What to do if Leica Geosystems RX1200 RX1250 does not connect to SmartAntenna?
If your Leica Geosystems Receiver RX1250 doesn't connect to the SmartAntenna, verify the SmartAntenna battery is charged and the SmartAntenna is switched on. Ensure correct configuration in CONFIGURE SmartAntenna Interface and that the correct cable (GEV 173, 8 pin Lemo connectors with green shielding) is being used.
Why Leica Geosystems RX1200 Receiver RX1250 does not recognise radio?
If your Leica Geosystems Receiver RX1250 doesn't recognize the radio, ensure the RX1250 is properly connected to GHT56 via clip-on-contacts. Also, verify the radio's battery is fully charged. The radio is powered by the battery attached to GHT56; a green LED indicator on GHT56 indicates sufficient power.
What to do if Leica Geosystems Receiver RX1250 does not recognise CompactFlash card?
If your Leica Geosystems Receiver RX1250 does not recognize the CompactFlash card, ensure the CompactFlash card is inserted and completely pushed in.
How to unhide function keys hidden by Windows CE task bar on Leica Geosystems Receiver?
If function keys on your Leica Geosystems Receiver are hidden by the Windows CE task bar, tap the Start button, select Settings\Taskbar and Start Menu, and under the General tab, tick the Auto hide option.
How to access Leica Geosystems software if not on Windows CE desktop?
To access the Leica software if you are not on the Windows CE desktop: Tap the Start button, select Programs\Leica Geosystems\GPS1200. Alternatively, access the Windows directory from the Windows CE Explorer and copy the Leica software icon to the Windows CE desktop. Note that the Leica software icon may be a hidden file.
General| Type | GNSS Receiver |
|---|---|
| Operating Temperature | -40°C to +65°C |
| Ingress Protection | IP67 |
| Battery Life | Up to 10 hours |
| Communication Interfaces | Bluetooth, USB |
Procedures for setting up RX1200 with holders and receivers.
Operating principles and procedures for handling and changing batteries.
Covers turning the RX1200 on/off and its operational states.
Procedures for connecting RX1250 to SmartAntenna, phones, and PCs.
Covers changing communication parameters, including radio settings.
Identifies potential hazards during use and provides necessary precautions.
Addresses common issues with powering on and establishing communication.
Detailed technical specifications for the RX1200 controller.
Technical specifications for the SmartAntenna.
Specifies measurement accuracy under different conditions.
