Leica BLK3D Mobile - 1 Instrument Components

1 Instrument Components
The Leica BLK3D Imager is a real-time, in picture 3D measurement solution. See chapter
Technical Data for scope of use.
20214_001
d
e
f
g
i
h
j
c
b
a
a Touch screen
b Laser/Photo capture
c Back
d Home
e Laser/Photo capture
f Recents
g Photo capture
h USB port protection lid
i USB port
j Power Functions
Instrument compon-
ents
7 Instrument Components
