What to do if I see a "POWER FAILURE" message on my Leica TP1020 Laboratory Equipment?
If you see the message "POWER FAILURE" on your Leica Laboratory Equipment, pressing any key will return the display to normal operation and silence the alarm.
What to do if the Leica TP1020 displays a "WRONG STATION" message?
If your Leica Laboratory Equipment displays a "WRONG STATION" message, simply press any key to return the display to normal and turn off the sound signal.
What does error code E:08, E:09 or E:10 mean on Leica TP1020 Laboratory Equipment?
If your Leica Laboratory Equipment shows error code "E:08" (Wax bath 1), "E:09" (Wax bath 2), or "E:10" (Wax bath 3), it could be due to several reasons: the wax bath is not connected, the excess temperature switch-off mechanism has been triggered, the wax bath is defective, or the control unit is defective. Here are a few things you can try: * Ensure the wax bath is properly connected. * Disconnect the wax bath connection plug from the socket at the rear of the instrument, allow the wax bath to cool down, and then reconnect it. If the yellow pilot lamp lights up, you can continue using the wax bath. * Exchange the wax bath.
What to do if Leica TP1020 Laboratory Equipment shows error code E:03, E:04, or E:05?
If your Leica Laboratory Equipment displays error code "E:03", "E:04", or "E:05", this indicates a drive malfunction. Try switching the main switch off and then back on, and try again.
What does error code E:11 mean on Leica TP1020?
If your Leica Laboratory Equipment displays error code "E:11", this indicates a loss of process data. Acknowledge the error message by pressing any key; the process will be canceled with an ABORT message. Restart the processing cycle.
What does error code E:12 mean on Leica Laboratory Equipment?
If your Leica Laboratory Equipment displays error code "E:12", it means there has been a loss of program settings. To resolve this, acknowledge the error message by pressing any key, which will cancel the process and display an ABORT message. Then, restart the processing cycle.
What to do if Leica TP1020 Laboratory Equipment displays warning code W:04, W:05, or W:06?
If your Leica Laboratory Equipment displays warning code "W:04", "W:05", or "W:06" when starting an automatic processing cycle, it means that the total program duration until the basket reaches the first wax bath is less than 8 hours, and the paraffin in stations 10/11/12 might still be solid. To address this: * Check if there is enough time for the paraffin to liquefy completely before the basket arrives at the wax bath. * If not, fill the wax bath with molten paraffin. To override the warning code, press the Key and Start buttons simultaneously.
What does warning code W:01, W:02, or W:03 mean on Leica Laboratory Equipment?
If your Leica Laboratory Equipment displays warning code "W:01", "W:02", or "W:03" in manual processing mode, it indicates that the paraffin in wax bath stations 10/11/12 is still solid. Here’s how to proceed: * Press any key to quit the warning code. * Check if the paraffin is molten. * If the paraffin is molten, pause the automatic processing cycle and, in manual processing mode, simultaneously press the Key and the corresponding Arrow key to lower or lift the basket in or out of the wax bath.
What does error code E:13 mean on Leica TP1020?
General| Type | Tissue Processor |
|---|---|
| Capacity | Up to 100 cassettes |
| Station volume | 1.8 liters |
| Power Supply | 100-240 V, 50/60 Hz |
| Processing Stations | 12 stations |
Explains symbols and their meanings for better understanding of the manual.
Identifies the specific instrument model and its general characteristics.
Specifies the necessary training and familiarity required for operating personnel.
Outlines the intended applications and processes for the instrument.
Provides essential safety information related to instrument operation and maintenance.
Details safety precautions for moving and setting up the instrument.
Covers essential safety measures to follow during instrument operation.
Specifies safety guidelines to be followed during the cleaning process.
Outlines safety considerations related to instrument maintenance procedures.
Highlights specific safety precautions and warnings related to wax bath usage.
Details safety information regarding the optional activated carbon filter.
Lists detailed technical specifications, dimensions, electrical data, and weights.
Provides a comprehensive overview of the instrument's functionality and design.
Details the standard configurations and included accessories with order numbers.
Illustrates the instrument with an optional wax bath, labeling key components.
Illustrates the instrument with a fume control system, labeling key components.
Describes the various accessories that come standard with the instrument.
Details the standard tissue basket, its capacity, and usage.
Describes the glass beaker with holder, including capacity and fill level marks.
Details aluminum containers used with vacuum function, including capacity and fill marks.
Describes the wax bath, its capacity, heating, and safety features.
Provides step-by-step guidance for safely unpacking the instrument.
Details the procedures for setting up the instrument on a laboratory bench.
Continues the unpacking instructions, covering further steps for setup.
Specifies the environmental and space conditions necessary for instrument installation.
Covers the process of connecting the instrument to the power supply.
Explains how to verify the correct voltage selector setting before connecting.
Details the procedure for adjusting the voltage selector if needed.
Guides on connecting the power cable correctly to the instrument and outlet.
Describes the initial steps for powering on the instrument.
Explains how to set the instrument's internal clock.
Provides instructions for installing various accessories onto the instrument.
Details the process of installing the wax baths into their respective stations.
Guides on correctly connecting the wax baths to the instrument's rear sockets.
Explains how to secure wax bath cables for instruments with fume control.
Describes how to mount the reagent containers onto the instrument's platform.
Describes the instrument's control panel layout, buttons, and display information.
Details the primary functions of the instrument's keys and controls.
Explains the operation of the carousel movement button for basket handling.
Covers controls for starting, pausing, resuming, stopping, and aborting processing cycles.
Describes manual operation keys, vacuum function, and programming mode buttons.
Provides an overview of how programs are created, set up, and edited.
Highlights unique features and behaviors of programs designed for two baskets.
Guides on the process of setting up and editing processing programs.
Explains how to enter the programming mode to set up or modify programs.
Details how to choose or select a specific program number for editing or use.
Guides on how to specify the number of baskets (1 or 2) for a program.
Explains how to define the initial station for a processing program.
Describes how to enable or disable the vacuum function within program settings.
Guides on setting the duration for infiltration at each processing station.
Shows how to view the total estimated time for a programmed cycle.
Details the procedure for exiting the programming mode after adjustments.
Provides instructions for filling the reagent stations with appropriate solutions.
Guides on how to safely fill the wax baths with paraffin.
Explains how to adjust the working temperature of the wax baths.
Details the steps for correctly inserting the tissue basket into the instrument.
Describes how to manually lift and lower the tissue basket between stations.
Explains how to advance the tissue basket to the subsequent station.
Guides on manually activating and deactivating the vacuum function.
Covers the procedures for initiating processing programs.
Details how to start a selected program immediately after setup.
Explains how to schedule a program to start at a future time.
Guides on modifying the scheduled start time for delayed programs.
Describes how to lock the control panel to prevent unintended changes.
Explains how to edit programs, with exceptions for the currently running one.
Shows how to check the estimated completion time of a processing cycle.
Describes how to temporarily stop an ongoing automatic processing cycle.
Explains how to restart a processing cycle that was previously paused.
Details how to stop or abort an active processing cycle.
Indicates what happens and how to proceed when an automatic process completes.
Provides steps for safely removing processed specimens from the instrument.
Outlines the necessary procedures to complete daily operations and secure the instrument.
Lists and explains warning codes, their causes, and how to handle them.
Provides a detailed list of error codes, their root causes, and solutions.
Details procedures for power failures, wrong station messages, and aborting processes.
Provides specific steps for manually removing the tissue basket during power failure.
Describes manual carousel movement and station skipping after a power failure.
Provides general guidelines and recommendations for instrument upkeep.
Focuses on maintenance procedures specifically for the wax bath component.
Explains how to adjust the wax bath's temperature setting.
Details the procedure to reset the instrument after an excess temperature shutdown.
Guides on how to safely replace the instrument's fuses.
Describes the features and capacity of the three-level tissue basket.
Details the basket removal device and its use for safely handling hot baskets.
Explains the accessory for adding a second tissue basket to increase throughput.
Provides instructions for installing the second basket holder.
Provides instructions for installing the station holder for accessories.
Guides on connecting an optional third wax bath to the instrument.
Details how to connect the fume outlet tube for exhaust ventilation.
Provides specific steps for installing the fume outlet tube.
Explains how to install activated carbon filters for fume control.
Lists various accessories available for order, along with their part numbers.
Covers user-configurable settings for the instrument's operation.
Explains how to access and enter the instrument's configuration menu.
Details how to change specific configuration parameters.
Describes the setting to enable or disable the third wax bath functionality.
Explains how to reset specific programs to their factory default settings.
Details the system reset function and its impact on instrument settings.
Guides on how to exit the instrument's configuration menu.
Lists the safe and recommended reagents for use with the TP1020.
Presents the default programs pre-configured in the instrument.
Details the settings for factory program number 6, designed for one basket.
Details the settings for factory program number 8, designed for two baskets.
Details the settings for factory program number 7, designed for one basket.
Details the settings for factory program number 9, designed for two baskets.
Provides a template for users to record custom program settings.
Outlines the terms and conditions of the product warranty.
Provides information on how to obtain technical support and spare parts.
Gives guidance on the proper disposal of the instrument at the end of its life.
