What to do if Leica EM ACE600 displays 'Process terminated, Sputter current could not be stabilized'?
If the Leica Laboratory Equipment process is terminated because the sputter current could not be stabilized due to unstable plasma current, the reason might be unclean target. Clean it with isopropanol and try again.
What to do if the Leica EM ACE600 process terminated, no power detected?
If the Leica Laboratory Equipment process is terminated and no power is detected, it's because the carbon thread supply is not powered. Check the door and cover sensors.
What to do if Leica Laboratory Equipment shows 'Door open'?
If the Leica Laboratory Equipment displays 'Door open', it means the process or pumping has been aborted. You should check the door sensor and close the door.
Why Leica EM ACE600 displays 'No thread available'?
If the Leica Laboratory Equipment displays 'No thread available' because no threads are detected, abort the process only after resistance calculation.
What to do if Leica EM ACE600 Laboratory Equipment displays 'Process terminated, Quartz unstable'?
If the Leica Laboratory Equipment process is terminated because the quartz is unstable, change the quartz and try to run the process again. Measuring of frequency before process has to be stable to guarantee valid measurement.
What to do if Leica EM ACE600 displays 'head (1) not connected'?
If the Leica Laboratory Equipment displays 'head (1) not connected' and the process is aborted because the specific head is not connected, connect the cable.
What to do if Leica Laboratory Equipment displays 'Lift motor error detected'?
If the Leica Laboratory Equipment displays 'Lift motor error detected' because the initialization of the lift motor failed, try re-initialization and learning.
What to do if Leica EM ACE600 displays 'Shutter motor error detected'?
If the Leica Laboratory Equipment displays 'Shutter motor error detected' because the initialization of the shutter motor failed, try re-initialization and learning.
What to do if Leica Laboratory Equipment displays 'head (2) not connected'?
If the Leica Laboratory Equipment displays 'head (2) not connected' and the process is aborted because the specific head is not connected, connect the cable.
What to do if Leica EM ACE600 displays 'No gauge detected'?
If the Leica Laboratory Equipment displays 'No gauge detected' at start-up of software, restart the device.
Safety precautions for operation, maintenance, installation, and emergency procedures.
Workspace needs, workbench size, electrical/gas connections, and vacuum hygiene.
Explains the LCD control panel for system communication, data input/output, and process parameter editing.
Procedures for pumping down the system to vacuum and venting it, with status indicators.
Explanation of the QSG system for measuring film thickness and its role in process termination.
Details on performing carbon thread coating, including pulse/flash modes and material recommendations.
Explanation of the magnetron sputter coating process, targets, and argon gas supply requirements.
Lists common error messages, their possible causes, and remedies for vacuum, shutter, quartz, and sputtering issues.
Detailed list of system, HiVac controller, and carbon thread controller error codes, titles, messages, and descriptions.
General| Type | High Vacuum Coating System |
|---|---|
| Weight | 80 kg (approximate, without pumps) |
| Application | Sample preparation for electron microscopy |
| Coating Method | Sputtering |
| Coating Techniques | Carbon coating |
| Coating Materials | Gold, platinum, carbon, chromium |
| Target Material | Depends on the coating material used |
| Maximum Sample Size | Up to 100 mm |
| Chamber Size | 200 mm diameter |
| Vacuum System | Turbo molecular pump |
| Operating Pressure | 10^-6 mbar |
| Control System | Microprocessor-controlled |
| Sample Stage | Rotatable and adjustable |
| Thickness Monitoring | Quartz crystal monitor |
| Gas Flow Control | Mass flow controller |
| Dimensions (W x D x H) | 600 x 500 x 500 mm |
