Leica T-Scan 5 User Manual

Optimal distance:
007454_001
a
b
d
c
e
a Emerging laser beam
b Pilot beam
c Reflected beam
d Trigger key
e Stand-off indicator LED
Distance too large:
007504_001
a
b
d
c
e
a Emerging laser beam
b Pilot beam (above the
scan line)
c Reflected beam
d Trigger key
e Stand-off indicator LED
