MS50/TS50/TM50, Technical Data
72
Atmospheric
conditions

Measurements can be made to reflector tapes over the entire range without external
ancillary optics.
Accuracy Accuracy refers to measurements to standard prisms.
For TS50/TM50 - R1000:
Beam interruptions, severe heat shimmer and moving objects within the beam path
can result in deviations of the specified accuracy.
For MS50 - R2000:
Beam interruptions, severe heat shimmer and moving objects within the beam path
can result in deviations of the specified accuracy.
Characteristics
Range A: Strong haze, visibility 5 km; or strong sunlight, severe heat shimmer
Range B: Light haze, visibility about 20 km; or moderate sunlight, slight heat
shimmer
Range C: Overcast, no haze, visibility about 40 km; no heat shimmer
EDM
measuring mode
std. dev.
ISO 17123-4,
standard prism
std. dev.
ISO 17123-4,
tape**
Measurement
time, typical [s]
Precise 0.6 mm + 1 ppm* 1 mm + 1 ppm 7
Standard 1 mm + 1 ppm 1 mm + 1 ppm 2.4
Fast 2 mm + 1 ppm 3 mm + 1 ppm 2.0
Continuous 3 mm + 1 ppm 3 mm + 1 ppm < 0.15
Averaging 1 mm + 1 ppm 1 mm + 1 ppm -
Continuous+ 3 mm + 1 ppm 3 mm + 1 ppm < 0.15
* Atmospheric conditions type C, range up to 1000 m, GPH1P reflector
** Target aligned to instrument
EDM
measuring mode
std. dev.
ISO 17123-4,
standard prism
std. dev.
ISO 17123-4,
tape*
Measurement
time, typical [s]
Standard 1 mm + 1.5 ppm 1 mm + 1.5 ppm 1.5
Fast 2 mm + 1.5 ppm 3 mm + 1.5 ppm 1.0
Continuous 2 mm + 1.5 ppm 3 mm + 1.5 ppm >0.05**
Averaging 1 mm + 1.5 ppm 1 mm + 1.5 ppm -
Continuous+ 2 mm + 1.5 ppm 3 mm + 1.5 ppm >0.05**
* Target aligned to instrument
** Auto point application increases the measurement time
Type: Coaxial, visible red laser
Carrier wave: 658 nm
Measuring system: R1000: System Analyzer Basis 100 MHz - 150 MHz
R2000: Wave Form Digitizer
