MS50/TS50/TM50, Technical Data
91
7.12 General Technical Data of the Instrument
Telescope
Compensator
Level
Control unit
Instrument Ports
Magnification: 30 x
Clear objective diameter: 40 mm
Focusing: 1.7 m/5.6 ft to infinity
Field of view: 1°30’/1.66 gon.
2.7 m at 100 m
Type Setting accuracy Setting range
["] [mgon] [’] [gon]
All types 0.5 0.15 4 0.07
Compensation: Centralised quadruple axis compensation
Circular level sensitivity: 6’/2 mm
Electronic level resolution: 2"
Display: VGA (640 x 480 pixels), colour, graphics capable
LCD, illumination, touch screen
Keyboard: 34 keys
including 12 function keys, 12 alphanumeric keys
and a user defined SmartKey, illumination
Angle Display: 360°’", 360° decimal, 400 gon, 6400 mil, V %
Distance Display: m, ft int, ft us, ft int inch, ft us inch
Position: TM50 face I only, TS50/MS50 both faces
Touch screen: Toughened film on glass
Name Description
Serial/USB • 8 pin LEMO-1 for power, communication, data transfer.
• This port is located at the base of the instrument.
Handle • Hotshoe connection for RadioHandle with Remote Mode and Smart-
Antenna Adapter with SmartStation.
• This port is located on top of the Communication side cover.
BT • Bluetooth module for communication.
• This port is housed within the Communication side cover.
WLAN • WLAN module for communication.
• This port is housed within the Communication side cover.
