7.3 Distance Measurement without Reflectors
Range
Range of measurement:
Atmospheric
conditions
Accuracy For TS50/TM50 - R1000:
Object in shade, sky overcast. Beam interruptions, severe heat shimmer and moving
objects within the beam path can result in deviations of the specified accuracy. The
display resolution is 0.1 mm.
For MS50 - R2000:
Object in shade, sky overcast. Beam interruptions, severe heat shimmer and moving
objects within the beam path can result in deviations of the specified accuracy. The
display resolution is 0.1 mm.
Characteristics
Type Kodak Gray
Card
Range D Range E Range F
[m] [ft] [m] [ft] [m] [ft]
R1000 White side, 90 %
reflective
800 2630 1000 3280 >1000 >3280
R1000 Grey side, 18 %
reflective
400 1320 500 1640 >500 >1640
R2000 White side, 90 %
reflective
1500 4920 2000 6560 >2000 >6560
R2000 Grey side, 18 %
reflective
750 2460 1000 3280 >1000 >3280
R1000: 1.5 m - 1200 m
R2000: 1.5 m - 2400 m
Distance measurements below 1.5 m are not possible.
D: Object in strong sunlight, severe heat shimmer
E: Object in shade, sky overcast
F: Underground, night and twilight
Standard measuring std. dev.
ISO 17123-4
Measure time,
typical [s]
Measure time,
maximum [s]
0 m - 500 m 2 mm + 2 ppm 3 12
>500 m 4 mm + 2 ppm 6 12
Standard measuring std. dev.
ISO 17123-4
Measure time,
typical [s]
Measure time,
maximum [s]
0 m - 500 m 2 mm + 2 ppm 1.5 12
>500 m 4 mm + 2 ppm 4 12
* Auto point application increases the measurement time
Type: Coaxial, visible red laser
Carrier wave: 658 nm
Measuring system: R1000: System Analyzer Basis 100 MHz - 150 MHz
R2000: Wave Form Digitizer
