Operation
164
Because of the limited content of the fresh water tank we recom-
mend that
for the cleaning of empty spraying agent canisters or
flushing of the induction system with fresh water,
fresh water is sucked in from a filler hose via the selector valve,
See "Filling the main tank with water, page 139".
9.12 Flushing the induction system
After cleaning empty spraying agent canisters, the induction system can be flus-
hed with fresh water.
CAUTION
Spraying agent may cause damage to health and pollute the
environment.
When the cover is open, residual particles of spraying agent may
escape and cause a hazard to the operator and the environment.
The cover must be kept closed during flushing.
Close the cover (1) of the induction con-
tainer.
To flush the induction system, switch the
following levers up into the ON position:
Canister flushing nozzle
Edge wetting
1
