Maintenance and repairs
237
13.12.5 Folding cylinder
Boom with 2 folding cylinders
Lubricate each of the 2 grease nipples
on the base of the piston (1) and on the
piston rod (2) of the folding cylinder (1)
every 8 operating hours.
Boom with 4 folding cylinders
Lubricate each of the 4 grease nipples
on the base of the piston (1) and on the
piston rod (2) of the folding cylinder (1)
every 8 operating hours.
13.12.6 Swivel joint
Lubricate the 4 grease nipples of the
swivel joint (1) every 8 operating hours.
1
2
1
1
