Page 30
Assy, Tension Knob
1 x 0270
Includes:
Tension Knob/Rod
*Cover
Spring
2 x 0273
**Detent Nut
***Acorn Nut
1 x 0274
Screw, Tension Knob
2 x M610
**Detent Nut
***Acorn Nut
*Cover
FIGURES
Figure 7: Brake Tension Knob Assembly
