LeMond REvMaster - Figure 8: Brake Pad Assembly

Page 31
FIGURES
Leather Brake Pad w/Foam 1 x 11252
Brake Pad Holder (comes with leather brake pad) 1 x 0220
Rubber Bumper 1 x 9723
Spring Steel w/ Foam
Screws, M6 x 20 4 x H620
(H620)
Screw, M6 x 10 1 x M610
Nut, M6 1 x 6600
(H620)
Figure 8: Brake Pad Assembly
