ISC Communications
258 —
revision 7
2. Click on the IP Programming tab.
3. In the Device Control Box, click [Retrieve]. A confirmation message will be displayed. Click [OK] to
populate the TCP/IP setting field boxes.
4. Click [Program]. A confirmation message will be displayed. Click [OK] to begin programming the
device.
5. The unit must be reset. Click [Reset] and the unit programming will be completed.
6. Restart the computer.
Configure Ports
1. In the Device Manager, expand Multi-port serial adapters. Right-click the RocketPort Serial Hub port
and select Properties.
2. On the Main Setup tab, select the port being used for communication and click [Properties].
3. For RS-485 2-wire communication, use the following settings:
4. On the RTS Toggle tab, select RTS Toggle RTS Low.
5. Click [OK].
41.16 IFS Single/Multi-mode Duplex Data Transmitters Receivers
(DFDMM001-TX and 7DFDMM001-RX)
Note: These configuration instructions are for use with the OnGuard software. For detailed
installation and configuration information, refer to the Single Multi-Mode Duplex Data
Transmitters Receivers Installation Guide which is included with the device.
The data series fiber transmission products support optical transmission bi-directional data through one fiber
either in multi-mode or single-mode. The modules support data interface. They are single-unit designed for
both rack mount and wall mount configurations. Plug-and-Play design ensures ease of installation requiring
no electrical or optical adjustments.
Port Setup
RS mode: 485
Override and lock baud rate to: None
Timeout on transmit data on port close: 0 sec
Inactive Timeout Period: 120 sec
Map 2 stop bits to 1 unchecked
Wait on physical transmission before completing write unchecked
Emulate modem hardware TRING signal unchecked
COM name: Select appropriate name
