41.16.3 DIP Switch Settings and Connections
41.16.4 LED Indicators
Model Mode DIP switches Terminal Upstream Port
DFDMM001-TX 2-wire RS-485 SW 3 ON,
SW 1, 2, 4 off
6TR+
7TR-
DFDMM001-RX 2-wire RS-485 SW 3 ON,
SW 1, 2, 4 off
6TR+
7TR-
DFDMM001-TX
Indicator Color Description
PWR Red Lit when power is supplied to the Transmitter.
OL Red Lit when fiber is not connected or without proper fiber
connection.
Green Lit when optical signal from receiver to transmitter is active.
Data IN Green Blinks when forward input data is available at Tx.
Data OUT Green Blinks when reverse output data is available at Tx.
Signal Ports
OPT - ST (or FC) Optical Connector for fiber cable connection.
DATA - 7-pin Screw Terminal Block for data signal.
DFDMM001-RX
Indicator Color Description
PWR Red Lit when power is supplied to the Receiver.
OL Red Lit when fiber is not connected or without proper fiber
connection.
Green Lit when optical signal from transmitter to receiver is active.
Data IN Green Blinks when forward input data is available at Rx.
Data OUT Green Blinks when reverse output data is available at Rx.
Signal Ports
OPT - ST (or FC) Optical Connector for fiber cable connection.
DATA - 7-pin Screw Terminal Block for data signal.
