Page 8
Refrigerant Line Set
s:
T
ransition From V
ertical T
o Horizontal
Liquid Line
V
apor Line
Wrapped in
Armaflex
S
trap Liquid Line
T
o V
apor Line
Metal
Sleeve
Anchored Heavy
Nylon Wire T
ie
Automotive
Muffler-T
ype
Hanger
W
all
S
tud
W
all
S
tud
Liquid Line
V
apor Line
Wrapped in
Armaflex
S
trap Liquid Line
T
o V
apor Line
Metal
Sleeve
Figure 6
Outside
Unit Placement and Installation
Install unit away from windows.
T
wo 90° elbows
installed
in line set
will reduce line set
vibration.
Figure 7
9
11
