Page 2
Unit Dimensions − inches (mm)
SIDE VIEW
VAPOR &
LIQUID LINE
CONNECTION
INLET
AIR
INLET
AIR
DISCHARGE AIR
SIDE VIEW
TOP VIEW
A
OUTDOOR
COIL FAN
COMPRESSOR
INLET AIR
INLET AIR
B
2−3/4 (70)
ELECTRICAL
INLETS
OPTIONAL UNIT
STAND−OFF KIT (4)
(Field Installed)
4−3/8
(111)
6−3/8
(162)
6−3/8
(162)
TOP VIEW BASE SECTION
2 (51)
3/4
(19)
4−3/8
(111)
4−3/8
(111)
4−3/8
(111)
4−3/8
(111)
4−3/8
(111)
COMPRESSOR
COIL DRAIN OUTLETS
(Around perimeter of base)
OPTIONAL UNIT
STAND−OFF KIT (4)
(Field Installed)
LIQUID LINE
CONNECTION
VAPOR LINE
CONNECTION
C
C
Model No. A B C
10ACC−018 10ACC−024 030
in. 25 24−1/4 22−1/4
10ACC
−
018
,
10ACC
−
024
,
030
mm 635 616 565
10ACC 036
in. 25 24−1/4 24−1/4
10ACC−036
mm 635 616 616
10ACC−036 (Canada only)
10ACC 042
in. 29 28−1/4 24−1/4
(y)
10ACC−042
mm 737 718 616
10ACC 048
in. 33 32−1/4 24−1/4
10ACC−048
mm 838 819 616
10ACC 060
in. 37 36−1/4 28−1/4
10ACC−060
mm 940 921 718
