Lennox 13ACX User Manual

Page 25
13ACX SERIES
Start-Up and Performance Checklist
Job Name Job no. Date
Job Location City State
Installer City State
Unit Model No. Serial No. Service Technician
Nameplate Voltage
Rated Load Ampacity Compressor Outdoor Fan
Maximum Fuse or Circuit Breaker
Electrical Connections Tight?  Indoor Filter clean?  Supply Voltage (Unit Off)
Indoor Blower RPM S.P. Drop Over Indoor (Dry) Outdoor Coil Entering Air Temp.
Discharge Pressure Suction Pressure Refrigerant Charge Checked? 
Refrigerant Lines: Leak Checked?  Properly Insulated?  Outdoor Fan Checked? 
Service Valves: Fully Opened?  Caps Tight?  Thermostat
Voltage With Compressor Operating Calibrated?  Properly Set?  Level? 

Lennox 13ACX Specifications

General

Compressor	Single-stage
Sound Rating	76 dB
Refrigerant	R-410A
Operating Voltage	208/230V
Phase	1
Warranty	5-Year Limited Warranty on covered components
Cooling Capacity (BTU/h)	18, 000 - 60, 000
