Page 8
Unit Dimensions - Inches (mm)
SUCTION AND LIQUID
LINE CONNECTION
DISCHARGE AIR
SIDE VIEW
OUTDOOR
COIL FAN
COMPRESSOR
A
B
A
OPTIONAL UNIT STANDOFF KIT (4)
(FIELD INSTALLED)
SIDE VIEW
Model Numbers A B
13ACX-018-230-01 24-1/4 (616) 29-1/4 (743)
13ACX-018-230-02 and later 24-1/4 (616) 25-1/4 (641)
13ACX-024-230-01 24-1/4 (616) 33-1/4 (845)
13ACX-024-230-02 and later 24-1/4 (616) 25-1/4 (641)
13ACX-030-230-XX (All) 24-1/4 (616) 29-1/4 (743)
13ACX-036-230-XX (All) 24-1/4 (616) 29-1/4 (743)
13ACX-042-230-01 28-1/4 (718) 33-1/4 (845)
13ACX-042-230-02 and later 28-1/4 (718) 29-1/4 (743)
13ACX-048-230-01 28-1/4 (718) 29-1/4 (743)
13ACX-048-230-02 through -16 28-1/4 (718) 37-1/4 (946)
13ACX-048-230-17 28-1/4 (718) 33-1/4 (845)
13ACX-060-230-01 28-1/4 (718) 43-1/4 (1099)
13ACX-060-230-02 28-1/4 (718) 37-1/4 (946)
13ACX-060-230-03 through -16 28-1/4 (718) 33-1/4 (845)
13ACX-060-230-17 28-1/4 (718) 29-1/4 (743)
WARNING
This product and/or the indoor unit it is matched with may
contain fiberglass wool.
Disturbing the insulation during installation,
maintenance, or repair will expose you to fiberglass wool
dust. Breathing this may cause lung cancer. (Fiberglass
wool is known to the State of California to cause cancer.)
Fiberglass wool may also cause respiratory, skin, and
eye irritation.
To reduce exposure to this substance or for further
information, consult material safety data sheets
available from address shown below, or contact your
supervisor.
Lennox Industries Inc.
P.O. Box 799900
Dallas, TX 75379-9900
CAUTION
Physical contact with metal edges and corners while
applying excessive force or rapid motion can result in
personal injury. Be aware of, and use caution when
working near these areas during installation or while
servicing this equipment.
