Electrical Data
208/230V-60 Hz-1 Ph
Model Number
Label
Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
13ACX-018-230-01
1.0, 2.0 &
3.0
20 12.3 9.0 48.0 1/5 1075 1.1 2.0
13ACX-018-230-02 1.0 20 12.0 9.0 48.0 1/10 1075 0.7 1.4
13ACX-018-230-03 1.0 20 13.0 9.0 48.0 1/4 1080 1.7 3.4
13ACX-018-230-10 1.0 20 12.0 9.0 48.0 1/10 1075 0.7 1.4
13ACX-018-230-11
1.0 20 10.9 8.1 39.0 1/10 1075 0.7 1.4
2.0 15 9.8 7.3 39.0 1/10 1075 0.7 1.4
3.0 20 12.0 9.0 39.0 1/10 1075 0.7 1.4
13ACX-018-230-12 1.0 20 12.0 9.0 48.0 1/10 1075 0.7 1.4
13ACX-018-230-13
1.0 15 9.8 7.3 39.0 1/10 1075 0.7 1.4
2.0 20 12.0 9.0 39.0 1/10 1075 0.7 1.4
13ACX-018-230-14 1.0 & 2.0 20 12.0 9.0 39.0 1/10 1075 0.7 1.4
13ACX-018-230-15 1.0 & 2.0 20 12.0 9.0 39.0 1/10 1075 0.7 1.4
13ACX-018-230-17
1.0 15 10.9 8.1 39.0 1/10 1075 0.7 1.4
2.0 20 12.0 9.0 39.0 1/10 1075 0.7 1.4
13ACX-018-230-18 1.0 20 12.0 9.0 48.0 1/10 1075 0.7 1.4
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
208/230V-60 Hz-1 Ph
Model Number
Label
Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
13ACX-024-230-01
1.0, 2.0
and 3.0
30 17.9 13.4 58.3 1/5 1075 1.1 2.0
13ACX-024-230-02 1.0 30 17.5 13.4 58.3 1/10 1075 0.7 1.4
13ACX-024-230-03 1.0 30 18.5 13.4 58.3 1/4 1080 1.7 3.4
13ACX-024-230-10 1.0 30 17.5 13.4 58.3 1/10 1075 0.7 1.4
13ACX-024-230-11
1.0 30 17.5 13.4 53.3 1/10 1075 0.7 1.4
2.0 20 14.1 10.7 53.0 1/10 1075 0.7 1.4
3.0 20 13.1 9.9 53.0 1/10 1075 0.7 1.4
4.0 30 17.5 13.4 53.3 1/10 1075 0.7 1.4
13ACX-024-230-12
1.0 30 17.5 13.4 58.3 1/10 1075 0.7 1.4
2.0 30 17.5 13.46 58.3 1/10 1075 0.7 1.4
13ACX-024-230-13
1.0 20 13.1 9.9 53.0 1/10 1075 0.7 1.4
2.0 30 17.5 13.4 53.0 1/10 1075 0.7 1.4
13ACX-024-230-15 1.0 & 2.0 30 17.5 13.4 53.0 1/10 1075 0.7 1.4
13ACX-024-230-17
1.0 20 14.1 10.7 53.0 1/10 1075 0.7 1.4
2.0 30 17.5 13.46 53.0 1/10 1075 0.7 1.4
13ACX-024-230-18 1.0 30 17.6 13.5 58.3 1/10 1075 0.7 1.4
13ACX-024-230-19 1.0 30 17.5 13.46 58.0 1/10 1075 0.7 1.4
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
