13ACX SERIES
208/230V-60 Hz-1 Ph
Model Number
Label
Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
13ACX-030-230-01
1.0, 2.0 &
3.0
30 18.7 14.1 73.0 1/5 1075 1.1 2.0
13ACX-030-230-02 1.0 30 18.7 14.1 73.0 1/5 1075 1.1 2.0
13ACX-030-230-03 1.0 30 19.3 14.1 73.0 1/4 1080 1.7 3.4
13ACX-030-230-10 1.0 30 18.7 14.1 73.0 1/5 1075 1.1 2.0
13ACX-030-230-11
1.0 30 29.3 12.9 59.0 1/5 1075 1.1 2.0
2.0 30 15.6 11.6 59.0 1/5 1075 1.1 2.0
3.0 25 16.3 12.2 59.0 1/5 1075 1.1 2.0
4.0 30 18.7 14.1 59.0 1/5 1075 1.1 2.0
13ACX-030-230-12 1.0 30 18.7 14.1 73.0 1/5 1075 1.1 2.0
13ACX-030-230-13
1.0 25 16.3 12.2 59.0 1/5 1075 1.1 2.0
2.0 30 18.7 14.1 59.0 1/5 1075 1.1 2.0
13ACX-030-230-15 1.0 & 2.0 30 18.7 14.1 59.0 1/5 1075 1.1 2.0
13ACX-030-230-17
1.0 25 15.6 11.6 59.0 1/5 1075 1.1 2.0
2.0 30 18.7 14.1 59.0 1/5 1075 1.1 2.0
13ACX-030-230-18 1.0 30 18.7 14.1 73.0 1/5 1075 1.1 2.0
13ACX-030-230-19
1.0 25 17.1 12.8 64.0 1/5 1075 1.1 2.0
2.0 30 18.7 14.1 64.0 1/5 1075 1.1 2.0
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
208/230V-60 Hz-1 Ph
Model Number
Label
Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
13ACX-036-230-01
1.0, 2.0 &
3.0
35 21.9 16.6 79.0 1/5 1075 1.1 2.0
13ACX-036-230-02 1.0 35 21.9 16.6 79.0 1/5 1075 1.1 2.0
13ACX-036-230-04 1.0 35 22.5 16.6 79.0 1/5 1075 1.7 2.0
13ACX-036-230-10 1.0 35 21.9 16.6 79.0 1/5 1075 1.1 2.0
13ACX-036-230-11
1.0 35 21.9 16.6 70.0 1/5 1075 1.1 2.0
2.0 35 20.2 15.3 70.0 1/5 1075 1.1 2.0
3.0 35 21.9 16.6 70.0 1/5 1075 1.1 2.0
13ACX-036-230-12
1.0 35 21.8 16.7 79.0 1/5 1075 1.1 2.0
2.0 35 22.0 16.7 79.0 1/5 1075 1.1 2.0
13ACX-036-230-13 1.0 35 21.9 16.6 70.0 1/5 1075 1.1 2.0
13ACX-036-230-14 1.0 35 21.9 16.6 70.0 1/5 1075 1.1 2.0
13ACX-036-230-15 1.0 & 2.0 35 21.9 16.6 70.0 1/5 1075 1.1 2.0
13ACX-036-230-16 1.0 35 21.8 16.7 79.0 1/5 1075 1.1 2.0
13ACX-036-230-17
1.0 35 20.1 15.2 70.0 1/5 1075 1.1 2.0
2.0 35 22.0 16.7 70.0 1/5 1075 1.1 2.0
13ACX-036-230-18
1.0 35 21.9 16.7 79.0 1/5 1075 1.1 2.0
2.0 35 22.0 16.7 79.0 1/5 1075 1.1 2.0
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
