Lennox 13ACX User Manual

Page 6
208/230V-60 Hz-1 Ph
Model Number
Label
Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
13ACX-042-230-01
1.0, 2.0 &
3.0
40 24.1 17.9 112.0 1/3 1075 1.7 4.1
13ACX-042-230-03 1.0 40 25.2 17.9 112.0 1/2 1075 2.8 No Data
13ACX-042-230-10
1.0 40 24.1 17.9 112.0 1/4 825 1.7 3.1
2.0 40 25.3 18.8 112.0 1/4 825 1.7 3.1
13ACX-042-230-11
1.0 50 28.1 21.1 90.0 1/4 825 1.7 3.1
2.0 40 25.3 18.8 90.0 1/4 825 1.7 3.1
13ACX-042-230-12
1.0 40 24.1 17.9 112.0 1/4 825 1.7 3.1
2.0 40 25.3 18.8 112.0 1/4 825 1.7 3.1
3.0 45 28.1 21.2 112.0 1/4 825 1.7 3.1
13ACX-042-230-13 1.0 40 25.3 18.8 90.0 1/4 825 1.7 3.1
13ACX-042-230-14 1.0 40 25.3 18.8 90.0 1/4 825 1.7 3.1
13ACX-042-230-15 1.0 & 2.0 40 25.3 18.8 90.0 1/4 825 1.7 3.1
13ACX-042-230-16 1.0 40 25.3 18.8 112.0 1/4 825 1.7 3.1
13ACX-042-230-17 1.0 & 2.0 45 28.1 21.2 90.0 1/4 825 1.7 3.1
13ACX-042-230-18
1.0 40 24.1 18.0 112.0 1/4 825 1.7 3.1
2.0 & 3.0 45 28.1 21.2 112.0 1/4 825 1.7 3.1
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
208/230V-60 Hz-1 Ph
Model Number
Label
Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
13ACX-048-230-01
1.0, 2.0 &
3.0
50 28.9 21.8 117.0 1/4 825 1.7 3.1
13ACX-048-230-10 1.0 50 28.9 21.8 117.0 1/4 825 1.7 3.1
13ACX-048-230-11
1.0 50 28.9 21.8 117.0 1/4 825 1.7 3.1
2.0 45 27.7 20.8 100.0 1/4 825 1.7 3.1
3.0 50 28.9 21.8 100.0 1/4 825 1.7 3.1
13ACX-048-230-12
1.0 50 28.9 21.8 117.0 1/4 825 1.7 3.1
2.0 50 31.9 24.2 117.0 1/4 825 1.7 3.1
13ACX-048-230-13 1.0 50 28.9 21.8 100.0 1/4 825 1.7 3.1
13ACX-048-230-14 1.0 50 28.9 21.8 100.0 1/4 825 1.7 3.1
13ACX-048-230-15 1.0 & 2.0 50 28.9 21.8 100.0 1/4 825 1.7 3.1
13ACX-048-230-16 1.0 50 28.9 21.8 117.0 1/4 825 1.7 3.1
13ACX-048-230-17
1.0 50 31.9 24.1 100.0 1/4 825 1.7 3.1
2.0 50 31.9 24.2 100.0 1/4 825 1.7 3.1
13ACX-048-230-18 1.0 50 28.9 21.8 117.0 1/4 825 1.7 3.1
13ACX-048-230-19 1.0 50 31.9 24.2 100.0 1/4 825 1.7 3.1
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
