Lennox 13ACX User Manual

Page 7
13ACX SERIES
208/230V-60 Hz-1 Ph
Model Number
Label
Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
13ACX-060-230-01 1.0 & 2.0 60 34.5 26.2 134.0 1/4 825 1.7 3.1
13ACX-060-230-02 1.0 & 2.0 60 34.5 26.2 134.0 1/4 825 1.7 3.1
13ACX-060-230-05 1.0 60 35.6 26.2 134.0 1/2 1075 2.8 No Data
13ACX-060-230-10 1.0 60 34.5 26.2 134.0 1/4 825 1.7 3.1
13ACX-060-230-11
1.0 60 34.5 26.2 134.0 1/4 825 1.7 3.1
2.0 50 33.0 25.1 120.0 1/4 825 1.7 3.1
3.0 60 34.6 26.3 120.0 1/4 825 1.7 3.1
13ACX-060-230-12 1.0 60 34.6 26.3 134.0 1/4 825 1.7 3.1
13ACX-060-230-13
1.0 50 33.1 25.1 120.0 1/4 825 1.7 3.1
2.0 60 34.6 26.3 120.0 1/4 825 1.7 3.1
13ACX-060-230-14 1.0 60 34.6 26.3 120.0 1/4 825 1.7 3.1
13ACX-060-230-15 1.0 & 2.0 60 34.6 26.3 120.0 1/4 825 1.7 3.1
13ACX-060-230-16 1.0 60 34.6 26.3 134.0 1/4 825 1.7 3.1
13ACX-060-230-17
1.0 50 29.4 22.1 125.0 1/4 825 1.7 3.1
2.0 60 34.6 26.3 125.0 1/4 825 1.7 3.1
13ACX-060-230-18 1.0 60 34.7 26.4 134.0 1/4 825 1.7 3.1
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
